Starters, Contactors & Control Panels

Heavy-Duty Motor Starters, Contactors & Water Pump Panels

Product Overview

Rectiva manufactures premium electrical control and starter systems, including DOL Oil-Immersed Motor Starters, Air Break Dry Starters, high-capacity CH-Contactors, and Submersible Pump Control Panels. Engineered using durable copper components, heavy-duty housing, and highly responsive overload relays, these devices ensure safe motor starting, runs, and protection under heavy agricultural, industrial, and domestic applications.

Applications

Rectiva Starters, Contactors and Control Panels are vital for machinery and pump protection:

Agricultural Water Pumps: Oil-immersed and dry starters route heavy currents safely to irrigation motor pumps.
Industrial Motor Control: High capacity contactors and air break starters control compressors, conveyor belts, and factory motors.
Submersible Control Panels: Fully integrated control boxes manage running and starting capacitors, overload tripping, and live panel indicator readouts.

DOL Oil-Immersed Motor Starter

Insulated three-phase starters for reliable industrial and agricultural pumps

The Rectiva Direct-On-Line Oil-Immersed Motor Starter is designed for smooth and reliable operation of three-phase induction motors. Its contacts and relays are fully immersed in high-grade insulating oil, providing excellent arc quenching, cooling, and long contact life. Built for heavy-duty performance, it ensures maximum protection against overloads and voltage drops.

★ Excellent arc quenching in oil
★ Reliable overload and drop protection
★ High-grade insulated copper contacts
★ Durable enclosure for rough setups

DOL Motor Starter

Technical Specifications

CAT NO.	(DOL) IMMERSED	PHASE	Package (Per Case)
REOI 715	7.5 , 10HP	Three	8 PCS.
REOI 716	12.5, 15 HP	Three	8 PCS.
REOI 717	20 HP	Three	8 PCS.

Air Break Dry Starter MK1 Type

Direct-on-line dry starters with quick overload thermal release

Rectiva Air Break DOL Dry Starter MK1 Type provides highly reliable thermal protection and rapid overcurrent trip control for three-phase motors. Deployed in compact dry enclosures, it features robust sheet steel construction, easy reset push buttons, and standard contact terminals for simple wiring.

★ High sensitivity thermal overload relays
★ Quick manual reset function
★ Dust-proof protective steel casing
★ Safe for industrial compressors and pumps

Air Break Dry Starter MK1 Type

Technical Specifications

CAT NO.	(ADS) MK 1 TYPE	PHASE	Package (Per Case)
REDS 718	10, 12.5 HP	Three	8 PCS.
REDS 719	15 HP	Three	8 PCS.

(ADS) CH-Type Starter (with 4-Pole Contactor)

Advanced dry motor starter fitted with robust 4-pole contactors

Designed for demanding three-phase setups, the CH-Type dry starter integrates a premium 4-pole contactor for high operational endurance and minimal heating. Offering safe, contact-free remote operation, it provides immediate isolation under phase failures or load surges.

★ Premium 4-pole contactor integrated
★ Phase failure and load drop sensitivity
★ Long electrical and mechanical life
★ Safe handling and wide voltage operations

(ADS) CH-Type Dry Starter

Technical Specifications

CAT NO.	(ADS) CH-TYPE	PHASE	Package (Per Case)
REDS 721	3, 5, 7.5 HP	Three	8 PCS.
REDS 722	10, 12.5 HP	Three	8 PCS.
REDS 723	15 HP	Three	8 PCS.

CH-Contactor

High-capacity two-pole and four-pole contactors for clean source switching

Rectiva CH-Contactors are engineered for remote circuit control and heavy switching cycles. Constructed with premium insulation and pure silver-alloy contacts to resist wear and prevent contact welds, they are available in 2-Pole and 4-Pole configurations ranging from 10A to 40A.

★ Silver alloy contact points
★ High thermal endurance
★ Available in 2-Pole & 4-Pole versions
★ Quick response time and safe operation

CH-Contactor

Technical Specifications

CAT NO.	CONTACTOR	POLE	Package (Per Case)
RECONT 735	10/16 AMP	TWO	48 PCS.
RECONT 736	25 AMP	TWO	48 PCS.
RECONT 737	40 AMP	TWO	48 PCS.
RECONT 738	16 AMP	FOUR	32 PCS.
RECONT 739	25 AMP	FOUR	32 PCS.
RECONT 740	40 AMP	FOUR	32 PCS.

Submersible Control Panel

Fitted with MCB, volt/amp meters, capacitors & contactors

Rectiva Submersible Control Panels are comprehensive pump control units designed for single-phase water pumps. Fully integrated with responsive MCBs, digital/analog voltmeter and ammeters, starting and running capacitors, push buttons, and heavy contactors, they provide complete motor protection against overloads and voltage swings.

★ Multi-parameter readout meters
★ High-capacitance starting & running capacitors
★ Secure manual push operation switches
★ Integrated MCB protection

Submersible Control Panel

Technical Specifications

CAT NO.	HP	PHASE	Package (Per Case)
RESCP 741	1 HP	SINGLE	10 PCS.
RESCP 742	1.5 HP	SINGLE	10 PCS.
RESCP 743	2 HP	SINGLE	10 PCS.
RESCP 744	3 HP	SINGLE	10 PCS.

Product Features

Heavy Duty Sheets: Fabricated using premium metal backplates and durable structural designs.
Pure Copper Conductors: Contacts and relays are fitted with premium grade copper for maximum load management.
Corrosion Protection: Fine powder coating protects panels and enclosures from rusting under damp agricultural settings.
Wide Relay Protection: Precision overload sensors to automatically break contact during motor locks or power surges.

Why Choose Rectiva?

Rectiva switchgear offers unmatched electrical safety, durability, and user protection:

Legacy of Quality: Founded by Mr. Suresh Kumar Yadav, whose commitment to safety and engineering excellence drives us forward.
Advanced MD Leadership: Directed by Mr. Jatin Yadav, utilizing modern materials and designs to achieve zero-defect quality.
Rigorous Testing Standards: Tested for heat resistance, insulating capacity, and load breaking currents before shipment.
